Description

The Fuel Off-Road Arc Dually series elevates the rugged functionality of the Arc line to meet the specific needs of dual-rear-wheel trucks. Featuring a convex front wheel and deep concave rear wheel, this series emphasizes heavy-duty load capacity. The Arc Dually is designed to handle the heavier payloads and towing demands typical of dual-rear-wheel trucks like the Chevy Silverado 3500HD, GMC Sierra 3500HD, RAM 3500, and Ford F-350 Super Duty. Available in a 20" diameter, it offers tailored options for dually configurations.

Select all options to view Specs

Locate Your Nearest Dealer Fitment Guide

Specifications Chart

20"

22"

Part#	Model	Finish	Size	Bolt Pattern	Backspace	Offset	Bore	Weight	Load	Lip Size	Cap	MSRP USD
D8672082A9	D867 ARC DUALLY	BLACKOUT	20X8.25	10X225	8.72	104mm	170.10	45.90 lbs	3750	1.11	1004-62BLD	$655.00
D8672082A935	D867 ARC DUALLY	BLACKOUT	20X8.25	10X225	-3.29	-201mm	170.10	45.18 lbs	3750	7.36	1004-63BLD	$655.00
D86720827235	D867 ARC DUALLY	BLACKOUT	20X8.25	8X165.1	-4.31	-227mm	117.00	53.80 lbs	3000	7.36	1005-28BLD	$655.00
D86720827225	D867 ARC DUALLY	BLACKOUT	20X8.25	8X165.1	-3.29	-201mm	117.00	48.95 lbs	3000	7.36	1005-28BLD	$655.00
D86720828D35	D867 ARC DUALLY	BLACKOUT	20X8.25	8X165.1	-4.82	-240mm	121.50	51.48 lbs	3000	7.88	1005-28BLD	$460.00
D867208272	D867 ARC DUALLY	BLACKOUT	20X8.25	8X165.1	8.72	104mm	117.00	44.30 lbs	3000	1.11	1005-27BLD	$655.00
D86720829245	D867 ARC DUALLY	BLACKOUT	20X8.25	8X200	-4.31	-227mm	142.00	51.82 lbs	3000	7.36	1005-30BLD	$460.00
D867208292	D867 ARC DUALLY	BLACKOUT	20X8.25	8X200	8.72	104mm	142.00	43.20 lbs	3000	1.11	1005-29BLD	$460.00
D86720829235	D867 ARC DUALLY	BLACKOUT	20X8.25	8X200	-3.29	-201mm	142.00	47.63 lbs	3000	7.36	1005-30BLD	$460.00
D86720829335	D867 ARC DUALLY	BLACKOUT	20X8.25	8X210	-4.31	-227mm	154.30	50.49 lbs	3000	7.36	1005-30BLD	$460.00
D867208293	D867 ARC DUALLY	BLACKOUT	20X8.25	8X210	8.72	104mm	154.30	42.80 lbs	3000	1.11	1005-29BLD	$460.00
D86720829345	D867 ARC DUALLY	BLACKOUT	20X8.25	8X210	-5.06	-246mm	154.30	49.94 lbs	3000	7.88	1005-30BLD	$655.00
D86720829325	D867 ARC DUALLY	BLACKOUT	20X8.25	8X210	-3.29	-201mm	154.30	46.97 lbs	3000	7.36	1005-30BLD	$460.00
D8682082A935	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	10X225	-3.29	-201mm	170.10	45.18 lbs	3750	7.36	1004-63GB	$679.00
D8682082A9	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	10X225	8.72	104mm	170.10	45.90 lbs	3750	1.11	1004-62GB	$679.00
D86820827245	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X165.1	-5.06	-246mm	117.00	52.58 lbs	3000	7.88	1005-28GB	$679.00
D86820827235	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X165.1	-4.31	-227mm	117.00	53.80 lbs	3000	7.36	1005-28GB	$579.00
D86820828D	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X165.1	8.72	104mm	121.50	44.10 lbs	3000	1.11	1005-27GB	$679.00
D86820827225	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X165.1	-3.29	-201mm	117.00	48.95 lbs	3000	7.36	1005-28GB	$579.00
D86820828D35	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X165.1	-4.82	-240mm	121.50	51.48 lbs	3000	7.88	1005-28GB	$579.00
D868208292	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X200	8.72	104mm	142.00	43.20 lbs	3000	1.11	1005-29GB	$579.00
D86820829245	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X200	-4.31	-227mm	142.00	51.82 lbs	3000	7.36	1005-30GB	$579.00
D86820829235	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X200	-3.29	-201mm	142.00	47.63 lbs	3000	7.36	1005-30GB	$579.00
D868208293	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X210	8.72	104mm	154.30	42.80 lbs	3000	1.11	1005-29GB	$579.00
D86820829335	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X210	-4.31	-227mm	154.30	50.49 lbs	3000	7.36	1005-30GB	$579.00
D86820829325	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X210	-3.29	-201mm	154.30	46.97 lbs	3000	7.36	1005-30GB	$579.00
D8912082A9	D891 ARC DUALLY	POLISHED	20X8.25	10X225	8.72	104mm	170.10	45.90 lbs	3750	0.95	1004-62	$775.00
D8912082A935	D891 ARC DUALLY	POLISHED	20X8.25	10X225	-3.29	-201mm	170.10	45.18 lbs	3750	7.36	1004-63	$775.00
D89120827225	D891 ARC DUALLY	POLISHED	20X8.25	8X165.1	-3.29	-201mm	117.00	48.95 lbs	3000	7.36	1005-28	$725.00
D89120828D	D891 ARC DUALLY	POLISHED	20X8.25	8X165.1	8.72	104mm	121.50	44.10 lbs	3000	0.95	1005-27	$725.00
D89120828D45	D891 ARC DUALLY	POLISHED	20X8.25	8X165.1	-5.81	-265mm	121.50	55.30 lbs	3000	7.88	1005-28	$725.00
D89120828D35	D891 ARC DUALLY	POLISHED	20X8.25	8X165.1	-4.82	-240mm	121.50	50.90 lbs	3000	7.88	1005-28	$725.00
D89120827235	D891 ARC DUALLY	POLISHED	20X8.25	8X165.1	-4.31	-227mm	117.00	53.80 lbs	3000	7.36	1005-28	$725.00
D89120827245	D891 ARC DUALLY	POLISHED	20X8.25	8X165.1	-5.06	-246mm	117.00	52.00 lbs	3000	7.88	1005-28	$725.00
D89120821745	D891 ARC DUALLY	POLISHED	20X8.25	8X170	-4.31	-227mm	125.10	53.14 lbs	3000	7.36	1005-28	$725.00
D89120821735	D891 ARC DUALLY	POLISHED	20X8.25	8X170	-3.29	-201mm	125.10	48.51 lbs	3000	7.36	1005-28	$725.00
D891208217	D891 ARC DUALLY	POLISHED	20X8.25	8X170	8.72	104mm	125.10	43.90 lbs	3000	0.95	1005-27	$725.00
D89120829245	D891 ARC DUALLY	POLISHED	20X8.25	8X200	-4.31	-227mm	142.00	51.82 lbs	3000	7.36	1005-30	$725.00
D89120829235	D891 ARC DUALLY	POLISHED	20X8.25	8X200	-3.29	-201mm	142.00	47.63 lbs	3000	7.36	1005-30	$725.00
D891208292	D891 ARC DUALLY	POLISHED	20X8.25	8X200	8.72	104mm	142.00	43.20 lbs	3000	0.95	1005-29	$725.00
D89120829335	D891 ARC DUALLY	POLISHED	20X8.25	8X210	-4.31	-227mm	154.30	50.49 lbs	3000	7.36	1005-30	$725.00
D891208293	D891 ARC DUALLY	POLISHED	20X8.25	8X210	8.72	104mm	154.30	42.80 lbs	3000	0.95	1005-29	$725.00
D89120829345	D891 ARC DUALLY	POLISHED	20X8.25	8X210	-5.06	-246mm	154.30	48.92 lbs	3000	7.88	1005-30	$725.00
D89120829325	D891 ARC DUALLY	POLISHED	20X8.25	8X210	-3.29	-201mm	154.30	46.97 lbs	3000	7.36	1005-30	$725.00

Part#	Model	Finish	Size	Bolt Pattern	Backspace	Offset	Bore	Weight	Load	Lip Size	Cap	MSRP USD
D8672282A9	D867 ARC DUALLY	BLACKOUT	22X8.25	10X225	8.72	104mm	170.10	51.80 lbs	3750	0.98	1004-62BLD	$719.00
D8672282A935	D867 ARC DUALLY	BLACKOUT	22X8.25	10X225	-3.29	-201mm	170.10	51.42 lbs	3750	7.36	1004-63BLD	$719.00
D86722827235	D867 ARC DUALLY	BLACKOUT	22X8.25	8X165.1	-4.31	-227mm	117.00	59.30 lbs	3000	7.36	1005-28BLD	$719.00
D86722828D35	D867 ARC DUALLY	BLACKOUT	22X8.25	8X165.1	-4.82	-240mm	121.50	56.76 lbs	3000	7.88	1005-28BLD	$610.00
D86722827225	D867 ARC DUALLY	BLACKOUT	22X8.25	8X165.1	-3.29	-201mm	117.00	54.23 lbs	3000	7.36	1005-28BLD	$719.00
D86722828D	D867 ARC DUALLY	BLACKOUT	22X8.25	8X165.1	8.72	104mm	121.50	50.30 lbs	3000	1.11	1005-27BLD	$610.00
D86722829245	D867 ARC DUALLY	BLACKOUT	22X8.25	8X200	-4.31	-227mm	142.00	57.10 lbs	3000	7.36	1005-30BLD	$610.00
D867228292	D867 ARC DUALLY	BLACKOUT	22X8.25	8X200	8.72	104mm	142.00	49.40 lbs	3000	1.11	1005-29BLD	$610.00
D86722829235	D867 ARC DUALLY	BLACKOUT	22X8.25	8X200	-3.29	-201mm	142.00	52.91 lbs	3000	7.36	1005-30BLD	$610.00
D867228293	D867 ARC DUALLY	BLACKOUT	22X8.25	8X210	8.72	104mm	154.30	49.00 lbs	3000	1.11	1005-29BLD	$610.00
D86722829345	D867 ARC DUALLY	BLACKOUT	22X8.25	8X210	-5.06	-246mm	154.30	55.22 lbs	3000	7.88	1005-30BLD	$719.00
D86722829335	D867 ARC DUALLY	BLACKOUT	22X8.25	8X210	-4.31	-227mm	154.30	55.99 lbs	3000	7.36	1005-30BLD	$610.00
D86722829325	D867 ARC DUALLY	BLACKOUT	22X8.25	8X210	-3.29	-201mm	154.30	52.02 lbs	3000	7.36	1005-30BLD	$719.00
D8682282A9	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	10X225	8.72	104mm	170.10	51.80 lbs	3750	0.98	1004-62GB	$759.00
D8682282A935	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	10X225	-3.29	-201mm	170.10	51.42 lbs	3750	7.36	1004-63GB	$759.00
D86822827235	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X165.1	-4.31	-227mm	117.00	59.30 lbs	3000	7.36	1005-28GB	$759.00
D86822828D35	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X165.1	-4.82	-240mm	121.50	56.76 lbs	3000	7.88	1005-28GB	$675.00
D86822827225	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X165.1	-3.29	-201mm	117.00	54.23 lbs	3000	7.36	1005-28GB	$759.00
D868228272	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X165.1	8.72	104mm	117.00	50.50 lbs	3000	1.11	1005-27GB	$759.00
D86822829235	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X200	-3.29	-201mm	142.00	52.91 lbs	3000	7.36	1005-30GB	$675.00
D868228292	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X200	8.72	104mm	142.00	49.40 lbs	3000	1.11	1005-29GB	$675.00
D86822829245	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X200	-4.31	-227mm	142.00	57.10 lbs	3000	7.36	1005-30GB	$675.00
D868228293	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X210	8.72	104mm	154.30	49.00 lbs	3000	1.11	1005-29GB	$675.00
D86822829335	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X210	-4.31	-227mm	154.30	55.99 lbs	3000	7.36	1005-30GB	$675.00
D86822829325	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X210	-3.29	-201mm	154.30	52.02 lbs	3000	7.36	1005-30GB	$759.00
D8912282A9	D891 ARC DUALLY	POLISHED	22X8.25	10X225	8.72	104mm	170.10	51.80 lbs	3750	0.98	1004-62	$850.00
D8912282A935	D891 ARC DUALLY	POLISHED	22X8.25	10X225	-3.29	-201mm	170.10	51.42 lbs	3750	7.36	1004-63	$850.00
D89122828D	D891 ARC DUALLY	POLISHED	22X8.25	8X165.1	8.72	104mm	121.50	50.30 lbs	3000	0.98	1005-27	$800.00
D89122828D35	D891 ARC DUALLY	POLISHED	22X8.25	8X165.1	-4.82	-240mm	121.50	56.20 lbs	3000	7.88	1005-28	$800.00
D89122827235	D891 ARC DUALLY	POLISHED	22X8.25	8X165.1	-4.31	-227mm	117.00	59.30 lbs	3000	7.36	1005-28	$800.00
D89122827225	D891 ARC DUALLY	POLISHED	22X8.25	8X165.1	-3.29	-201mm	117.00	54.23 lbs	3000	7.36	1005-28	$800.00
D89122827245	D891 ARC DUALLY	POLISHED	22X8.25	8X165.1	-5.06	-246mm	117.00	57.30 lbs	3000	7.88	1005-28	$800.00
D89122828D45	D891 ARC DUALLY	POLISHED	22X8.25	8X165.1	-5.81	-265mm	121.50	60.60 lbs	3000	7.88	1005-28	$800.00
D891228217	D891 ARC DUALLY	POLISHED	22X8.25	8X170	8.72	104mm	125.10	50.10 lbs	3000	0.98	1005-27	$800.00
D89122821735	D891 ARC DUALLY	POLISHED	22X8.25	8X170	-3.29	-201mm	125.10	53.79 lbs	3000	7.36	1005-28	$800.00
D89122821745	D891 ARC DUALLY	POLISHED	22X8.25	8X170	-4.31	-227mm	125.10	58.64 lbs	3000	7.36	1005-28	$800.00
D89122829245	D891 ARC DUALLY	POLISHED	22X8.25	8X200	-4.31	-227mm	142.00	57.10 lbs	3000	7.36	1005-30	$800.00
D89122829235	D891 ARC DUALLY	POLISHED	22X8.25	8X200	-3.29	-201mm	142.00	52.91 lbs	3000	7.36	1005-30	$800.00
D891228292	D891 ARC DUALLY	POLISHED	22X8.25	8X200	8.72	104mm	142.00	49.40 lbs	3000	0.98	1005-29	$800.00
D891228293	D891 ARC DUALLY	POLISHED	22X8.25	8X210	8.72	104mm	154.30	49.00 lbs	3000	0.98	1005-29	$800.00
D89122829335	D891 ARC DUALLY	POLISHED	22X8.25	8X210	-4.31	-227mm	154.30	55.99 lbs	3000	7.36	1005-30	$800.00
D89122829325	D891 ARC DUALLY	POLISHED	22X8.25	8X210	-3.29	-201mm	154.30	52.02 lbs	3000	7.36	1005-30	$800.00
D89122829345	D891 ARC DUALLY	POLISHED	22X8.25	8X210	-5.06	-246mm	154.30	54.22 lbs	3000	7.88	1005-30	$800.00
