Specifications Chart
16"
17"
18"
| Part# | Model | Finish | Size | Bolt Pattern | Backspace | Offset | Bore | Weight | Load | Lip Size | Cap | MSRP USD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KM54267042730 | KM542 IMPACT | SATIN BLACK | 16X7 | 5X110 | 5.18 | 30mm | 72.56 | 22.77 lbs | 1900 | 0.52 | T164H120A-5-H30-S1 | $202.00 |
| KM54267012730 | KM542 IMPACT | SATIN BLACK | 16X7 | 5X114.3 | 5.18 | 30mm | 72.56 | 22.77 lbs | 1900 | 0.52 | T164H120A-5-H30-S1 | $202.00 |
| KM54268058700 | KM542 IMPACT | SATIN BLACK | 16X8 | 5X150 | 4.50 | 00mm | 110.10 | 26.10 lbs | 2500 | 1.51 | T164H145-5-H46-S1 | $202.00 |
| KM54268068700 | KM542 IMPACT | SATIN BLACK | 16X8 | 6X139.7 | 4.50 | 00mm | 106.10 | 24.38 lbs | 2500 | 1.51 | T164H145-6-H30-S1 | $210.00 |
| KM54267042530 | KM542 IMPACT | SATIN BLACK MACHINED | 16X7 | 5X110 | 5.18 | 30mm | 72.56 | 22.77 lbs | 1900 | 0.52 | T164H120A-5-H30-S1 | $214.00 |
| KM54267012530 | KM542 IMPACT | SATIN BLACK MACHINED | 16X7 | 5X114.3 | 5.18 | 30mm | 72.56 | 22.77 lbs | 1900 | 0.52 | T164H120A-5-H30-S1 | $214.00 |
| KM54268058500 | KM542 IMPACT | SATIN BLACK MACHINED | 16X8 | 5X150 | 4.50 | 00mm | 110.10 | 26.10 lbs | 2500 | 1.51 | T164H145-5-H46-S1 | $214.00 |
| KM54268068500 | KM542 IMPACT | SATIN BLACK MACHINED | 16X8 | 6X139.7 | 4.50 | 00mm | 106.10 | 24.38 lbs | 2500 | 1.51 | T164H145-6-H30-S1 | $214.00 |
| Part# | Model | Finish | Size | Bolt Pattern | Backspace | Offset | Bore | Weight | Load | Lip Size | Cap | MSRP USD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KM54278045738 | KM542 IMPACT | SATIN BLACK | 17X8 | 5X108 | 6.00 | 38mm | 72.56 | 29.15 lbs | 2500 | 0.67 | T164H120A-5-H30-S1 | $229.00 |
| KM54278012735 | KM542 IMPACT | SATIN BLACK | 17X8 | 5X114.3 | 5.88 | 35mm | 72.56 | 29.15 lbs | 2500 | 0.67 | T164H120A-5-H30-S1 | $234.00 |
| KM54278050735 | KM542 IMPACT | SATIN BLACK | 17X8 | 5X127 | 5.88 | 35mm | 71.50 | 29.13 lbs | 2500 | 0.67 | T164H120-5-H30-S1 | $234.00 |
| KM54278064735 | KM542 IMPACT | SATIN BLACK | 17X8 | 6X114.3 | 5.88 | 35mm | 66.06 | 29.13 lbs | 2500 | 0.67 | T164H120-6-H30-S1 | $234.00 |
| KM54278077720 | KM542 IMPACT | SATIN BLACK | 17X8 | 6X120 | 5.29 | 20mm | 66.90 | 29.31 lbs | 2500 | 0.67 | T164H120-6-H30-S1 | $234.00 |
| KM54278062735 | KM542 IMPACT | SATIN BLACK | 17X8 | 6X139.7 | 5.88 | 35mm | 100.30 | 29.41 lbs | 2500 | 0.67 | T164H145-6-H30-S1 | $234.00 |
| KM54278068720 | KM542 IMPACT | SATIN BLACK | 17X8 | 6X139.7 | 5.29 | 20mm | 106.10 | 29.13 lbs | 2500 | 0.67 | T164H145-6-H30-S1 | $234.00 |
| KM54278550700 | KM542 IMPACT | SATIN BLACK | 17X8.5 | 5X127 | 4.75 | 00mm | 71.50 | 29.73 lbs | 2500 | 1.41 | T164H120-5-H30-S1 | $234.00 |
| KM54278563700 | KM542 IMPACT | SATIN BLACK | 17X8.5 | 6X135 | 4.75 | 00mm | 87.10 | 28.77 lbs | 2500 | 1.41 | T164H140-6-H30-S1 | $234.00 |
| KM54278568700 | KM542 IMPACT | SATIN BLACK | 17X8.5 | 6X139.7 | 4.75 | 00mm | 106.10 | 28.00 lbs | 2500 | 1.41 | T164H145-6-H30-S1 | $243.00 |
| KM54278580700 | KM542 IMPACT | SATIN BLACK | 17X8.5 | 8X165.1 | 4.75 | 00mm | 125.10 | 31.35 lbs | 3640 | 1.41 | T164H171-8-H65-S1 | $251.00 |
| KM54278587700 | KM542 IMPACT | SATIN BLACK | 17X8.5 | 8X170 | 4.75 | 00mm | 125.10 | 31.35 lbs | 3640 | 1.41 | T164H171-8-H77-S1 | $251.00 |
| KM54278588700 | KM542 IMPACT | SATIN BLACK | 17X8.5 | 8X180 | 4.75 | 00mm | 124.20 | 31.72 lbs | 3640 | 1.41 | T164H171-8-H65-S1 | $251.00 |
| KM54279050718 | KM542 IMPACT | SATIN BLACK | 17X9 | 5X127 | 5.71 | 18mm | 71.50 | 30.14 lbs | 2500 | 1.31 | T164H120-5-H30-S1 | $241.00 |
| KM54279050712N | KM542 IMPACT | SATIN BLACK | 17X9 | 5X127 | 4.53 | -12mm | 71.50 | 29.67 lbs | 2500 | 1.76 | T164H120-5-H30-S1 | $241.00 |
| KM54279064718 | KM542 IMPACT | SATIN BLACK | 17X9 | 6X114.3 | 5.71 | 18mm | 66.06 | 29.06 lbs | 2500 | 1.31 | T164H120-6-H30-S1 | $241.00 |
| KM54279063718 | KM542 IMPACT | SATIN BLACK | 17X9 | 6X135 | 5.71 | 18mm | 87.10 | 29.19 lbs | 2500 | 1.31 | T164H140-6-H30-S1 | $241.00 |
| KM54279068718 | KM542 IMPACT | SATIN BLACK | 17X9 | 6X139.7 | 5.71 | 18mm | 106.10 | 28.42 lbs | 2500 | 1.31 | T164H145-6-H30-S1 | $242.00 |
| KM54279068712N | KM542 IMPACT | SATIN BLACK | 17X9 | 6X139.7 | 4.53 | -12mm | 106.10 | 27.73 lbs | 2500 | 1.76 | T164H145-6-H30-S1 | $242.00 |
| KM54278045538 | KM542 IMPACT | SATIN BLACK MACHINED | 17X8 | 5X108 | 6.00 | 38mm | 72.56 | 28.95 lbs | 2500 | 0.67 | T164H120A-5-H30-S1 | $240.00 |
| KM54278012535 | KM542 IMPACT | SATIN BLACK MACHINED | 17X8 | 5X114.3 | 5.88 | 35mm | 72.56 | 28.95 lbs | 2500 | 0.67 | T164H120A-5-H30-S1 | $245.00 |
| KM54278068520 | KM542 IMPACT | SATIN BLACK MACHINED | 17X8 | 6X139.7 | 5.29 | 20mm | 106.10 | 29.31 lbs | 2500 | 0.67 | T164H145-6-H30-S1 | $245.00 |
| KM54278550500 | KM542 IMPACT | SATIN BLACK MACHINED | 17X8.5 | 5X127 | 4.75 | 00mm | 71.50 | 29.73 lbs | 2500 | 1.41 | T164H120-5-H30-S1 | $245.00 |
| KM54278563500 | KM542 IMPACT | SATIN BLACK MACHINED | 17X8.5 | 6X135 | 4.75 | 00mm | 87.10 | 28.77 lbs | 2500 | 1.41 | T164H140-6-H30-S1 | $245.00 |
| KM54278568500 | KM542 IMPACT | SATIN BLACK MACHINED | 17X8.5 | 6X139.7 | 4.75 | 00mm | 106.10 | 28.00 lbs | 2500 | 1.41 | T164H145-6-H30-S1 | $253.00 |
| KM54278580500 | KM542 IMPACT | SATIN BLACK MACHINED | 17X8.5 | 8X165.1 | 4.75 | 00mm | 125.10 | 31.35 lbs | 3640 | 1.41 | T164H171-8-H65-S1 | $251.00 |
| KM54278587500 | KM542 IMPACT | SATIN BLACK MACHINED | 17X8.5 | 8X170 | 4.75 | 00mm | 125.10 | 31.35 lbs | 3640 | 1.41 | T164H171-8-H77-S1 | $251.00 |
| KM54278588500 | KM542 IMPACT | SATIN BLACK MACHINED | 17X8.5 | 8X180 | 4.75 | 00mm | 124.20 | 31.72 lbs | 3640 | 1.41 | T164H171-8-H65-S1 | $251.00 |
| KM54279050512N | KM542 IMPACT | SATIN BLACK MACHINED | 17X9 | 5X127 | 4.53 | -12mm | 71.50 | 29.67 lbs | 2500 | 1.76 | T164H120-5-H30-S1 | $251.00 |
| KM54279050518 | KM542 IMPACT | SATIN BLACK MACHINED | 17X9 | 5X127 | 5.71 | 18mm | 71.50 | 30.14 lbs | 2500 | 1.31 | T164H120-5-H30-S1 | $251.00 |
| KM54279064518 | KM542 IMPACT | SATIN BLACK MACHINED | 17X9 | 6X114.3 | 5.71 | 18mm | 66.06 | 29.06 lbs | 2500 | 1.31 | T164H120-6-H30-S1 | $251.00 |
| KM54279063518 | KM542 IMPACT | SATIN BLACK MACHINED | 17X9 | 6X135 | 5.71 | 18mm | 87.10 | 29.19 lbs | 2500 | 1.31 | T164H140-6-H30-S1 | $251.00 |
| KM54279068512N | KM542 IMPACT | SATIN BLACK MACHINED | 17X9 | 6X139.7 | 4.53 | -12mm | 106.10 | 28.35 lbs | 2500 | 1.76 | T164H145-6-H30-S1 | $252.00 |
| KM54279068518 | KM542 IMPACT | SATIN BLACK MACHINED | 17X9 | 6X139.7 | 5.71 | 18mm | 106.10 | 28.42 lbs | 2500 | 1.31 | T164H145-6-H30-S1 | $252.00 |
| Part# | Model | Finish | Size | Bolt Pattern | Backspace | Offset | Bore | Weight | Load | Lip Size | Cap | MSRP USD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KM54289050718 | KM542 IMPACT | SATIN BLACK | 18X9 | 5X127 | 5.71 | 18mm | 71.50 | 31.62 lbs | 2500 | 1.34 | T164H120-5-H30-S1 | $279.00 |
| KM54289050700 | KM542 IMPACT | SATIN BLACK | 18X9 | 5X127 | 5.00 | 00mm | 71.50 | 30.26 lbs | 2500 | 1.57 | T164H120-5-H30-S1 | $279.00 |
| KM54289058718 | KM542 IMPACT | SATIN BLACK | 18X9 | 5X150 | 5.71 | 18mm | 110.10 | 30.03 lbs | 2500 | 1.34 | T164H145-5-H30-S1 | $279.00 |
| KM54289064718 | KM542 IMPACT | SATIN BLACK | 18X9 | 6X114.3 | 5.71 | 18mm | 66.06 | 31.49 lbs | 2500 | 1.34 | T164H120-6-H30-S1 | $279.00 |
| KM54289063700 | KM542 IMPACT | SATIN BLACK | 18X9 | 6X135 | 5.00 | 00mm | 87.10 | 29.30 lbs | 2500 | 1.57 | T164H140-6-H30-S1 | $279.00 |
| KM54289063718 | KM542 IMPACT | SATIN BLACK | 18X9 | 6X135 | 5.71 | 18mm | 87.10 | 31.62 lbs | 2500 | 1.34 | T164H140-6-H30-S1 | $279.00 |
| KM54289068700 | KM542 IMPACT | SATIN BLACK | 18X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 28.53 lbs | 2500 | 1.57 | T164H145-6-H30-S1 | $279.00 |
| KM54289068718 | KM542 IMPACT | SATIN BLACK | 18X9 | 6X139.7 | 5.71 | 18mm | 106.10 | 29.90 lbs | 2500 | 1.34 | T164H145-6-H30-S1 | $279.00 |
| KM54289050500 | KM542 IMPACT | SATIN BLACK MACHINED | 18X9 | 5X127 | 5.00 | 00mm | 71.50 | 30.26 lbs | 2500 | 1.57 | T164H120-5-H30-S1 | $272.00 |
| KM54289050518 | KM542 IMPACT | SATIN BLACK MACHINED | 18X9 | 5X127 | 5.71 | 18mm | 71.50 | 31.62 lbs | 2500 | 1.34 | T164H120-5-H30-S1 | $293.00 |
| KM54289064518 | KM542 IMPACT | SATIN BLACK MACHINED | 18X9 | 6X114.3 | 5.71 | 18mm | 66.06 | 31.49 lbs | 2500 | 1.34 | T164H120-6-H30-S1 | $293.00 |
| KM54289068500 | KM542 IMPACT | SATIN BLACK MACHINED | 18X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 28.53 lbs | 2500 | 1.57 | T164H145-6-H30-S1 | $293.00 |
| KM54289068518 | KM542 IMPACT | SATIN BLACK MACHINED | 18X9 | 6X139.7 | 5.71 | 18mm | 106.10 | 29.90 lbs | 2500 | 1.34 | T164H145-6-H30-S1 | $293.00 |
