MESA

KMC WHEELS

Be the first to review this product

MESA

KMC WHEELS

Be the first to review this product

This product is fitment specific

To see if this product is compatible Select a vehicle

Description

The KMC KM544 Mesa wheel is a no-nonsense street wheel with a rugged off-road personality. The KM544 wheel’s light weight, yet durable, construction is ready to take on the challenges ahead. The KM544 is truck tough and Jeep capable. From the job site to overland excursions, accent your rig with the KMC KM544 Mesa wheel.

Locate Your Nearest Dealer Fitment Guide Get in touch with our dedicated support staff

Specifications Chart

17"

18"

20"

Part#	Model	Finish	Size	Bolt Pattern	Backspace	Offset	Bore	Weight	Load	Lip Size	Cap	MSRP USD
KM54478550900	KM544 MESA	CANDY RED W/ BLACK LIP	17X8.5	5X127	4.75	00mm	71.50	32.03 lbs	2500	2.06	T164H120-5-H30-S5	$308.00
KM54478563900	KM544 MESA	CANDY RED W/ BLACK LIP	17X8.5	6X135	4.75	00mm	87.10	31.07 lbs	2500	2.06	T164H140-6-H30-S5	$308.00
KM54478568900	KM544 MESA	CANDY RED W/ BLACK LIP	17X8.5	6X139.7	4.75	00mm	106.10	30.30 lbs	2500	2.06	T164H145-6-H30-S5	$310.00
KM54479050918	KM544 MESA	CANDY RED W/ BLACK LIP	17X9	5X127	5.71	18mm	71.50	31.65 lbs	2500	1.87	T164H120-5-H30-S5	$327.00
KM54479050912N	KM544 MESA	CANDY RED W/ BLACK LIP	17X9	5X127	4.53	-12mm	71.50	32.42 lbs	2500	2.87	T164H120-5-H30-S5	$327.00
KM54479064918	KM544 MESA	CANDY RED W/ BLACK LIP	17X9	6X114.3	5.71	18mm	66.06	30.56 lbs	2500	1.87	T164H120-6-H30-S5	$327.00
KM54479068912N	KM544 MESA	CANDY RED W/ BLACK LIP	17X9	6X139.7	4.53	-12mm	106.10	30.69 lbs	2500	2.87	T164H145-6-H30-S5	$327.00
KM54479068918	KM544 MESA	CANDY RED W/ BLACK LIP	17X9	6X139.7	5.71	18mm	106.10	29.92 lbs	2500	1.87	T164H145-6-H30-S5	$327.00
KM54478568600	KM544 MESA	MATTE BRONZE W/ BLACK LIP	17X8.5	6X139.7	4.75	00mm	106.10	30.30 lbs	2500	2.06	T164H145-6-H30-S1	$293.00
KM54479050618	KM544 MESA	MATTE BRONZE W/ BLACK LIP	17X9	5X127	5.71	18mm	71.50	31.65 lbs	2500	1.87	T164H120-5-H30-S1	$303.00
KM54479050612N	KM544 MESA	MATTE BRONZE W/ BLACK LIP	17X9	5X127	4.53	-12mm	71.50	32.42 lbs	2500	2.87	T164H120-5-H30-S1	$303.00
KM54479064618	KM544 MESA	MATTE BRONZE W/ BLACK LIP	17X9	6X114.3	5.71	18mm	66.06	30.56 lbs	2500	1.87	T164H120-6-H30-S1	$303.00
KM54479068618	KM544 MESA	MATTE BRONZE W/ BLACK LIP	17X9	6X139.7	5.71	18mm	106.10	29.92 lbs	2500	1.87	T164H145-6-H30-S1	$303.00
KM54479068612N	KM544 MESA	MATTE BRONZE W/ BLACK LIP	17X9	6X139.7	4.53	-12mm	106.10	30.69 lbs	2500	2.87	T164H145-6-H30-S1	$303.00
KM54479080618	KM544 MESA	MATTE BRONZE W/ BLACK LIP	17X9	8X165.1	5.71	18mm	125.10	31.06 lbs	3640	1.87	T164H171-8-H65-S1	$327.00
KM54479087618	KM544 MESA	MATTE BRONZE W/ BLACK LIP	17X9	8X170	5.71	18mm	125.10	31.06 lbs	3640	1.87	T164H171-8-H77-S1	$327.00
KM54478550700	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	17X8.5	5X127	4.75	00mm	71.50	32.03 lbs	2500	2.06	T164H120-5-H30-S1	$293.00
KM54478563700	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	17X8.5	6X135	4.75	00mm	87.10	31.07 lbs	2500	2.06	T164H140-6-H30-S1	$293.00
KM54478568700	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	17X8.5	6X139.7	4.75	00mm	106.10	30.30 lbs	2500	2.06	T164H145-6-H30-S1	$293.00
KM54479050718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	17X9	5X127	5.71	18mm	71.50	31.65 lbs	2500	1.87	T164H120-5-H30-S1	$303.00
KM54479050712N	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	17X9	5X127	4.53	-12mm	71.50	32.42 lbs	2500	2.87	T164H120-5-H30-S1	$303.00
KM54479064718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	17X9	6X114.3	5.71	18mm	66.06	30.56 lbs	2500	1.87	T164H120-6-H30-S1	$303.00
KM54479063718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	17X9	6X135	5.71	18mm	87.10	30.69 lbs	2500	1.87	T164H140-6-H30-S1	$303.00
KM54479068718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	17X9	6X139.7	5.71	18mm	106.10	29.92 lbs	2500	1.87	T164H145-6-H30-S1	$303.00
KM54479068712N	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	17X9	6X139.7	4.53	-12mm	106.10	30.69 lbs	2500	2.87	T164H145-6-H30-S1	$303.00
KM54479080718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	17X9	8X165.1	5.71	18mm	125.10	31.06 lbs	3640	1.87	T164H171-8-H65-S1	$327.00
KM54479087718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	17X9	8X170	5.71	18mm	125.10	31.06 lbs	3640	1.87	T164H171-8-H77-S1	$327.00
KM54478550400	KM544 MESA	SATIN BLACK W/ GRAY TINT	17X8.5	5X127	4.75	00mm	71.50	32.03 lbs	2500	2.06	T164H120-5-H30-S3	$292.00
KM54478563400	KM544 MESA	SATIN BLACK W/ GRAY TINT	17X8.5	6X135	4.75	00mm	87.10	31.07 lbs	2500	2.06	T164H140-6-H30-S3	$292.00
KM54478568400	KM544 MESA	SATIN BLACK W/ GRAY TINT	17X8.5	6X139.7	4.75	00mm	106.10	30.30 lbs	2500	2.06	T164H145-6-H30-S3	$292.00
KM54479050412N	KM544 MESA	SATIN BLACK W/ GRAY TINT	17X9	5X127	4.53	-12mm	71.50	32.42 lbs	2500	2.87	T164H120-5-H30-S3	$301.00
KM54479050418	KM544 MESA	SATIN BLACK W/ GRAY TINT	17X9	5X127	5.71	18mm	71.50	31.65 lbs	2500	1.87	T164H120-5-H30-S3	$301.00
KM54479064418	KM544 MESA	SATIN BLACK W/ GRAY TINT	17X9	6X114.3	5.71	18mm	66.06	30.56 lbs	2500	1.87	T164H120-6-H30-S3	$301.00
KM54479068418	KM544 MESA	SATIN BLACK W/ GRAY TINT	17X9	6X139.7	5.71	18mm	106.10	29.92 lbs	2500	1.87	T164H145-6-H30-S3	$301.00
KM54479068412N	KM544 MESA	SATIN BLACK W/ GRAY TINT	17X9	6X139.7	4.53	-12mm	106.10	30.69 lbs	2500	2.87	T164H145-6-H30-S3	$301.00
KM54479080418	KM544 MESA	SATIN BLACK W/ GRAY TINT	17X9	8X165.1	5.71	18mm	125.10	31.06 lbs	3640	1.87	T164H171-8-H65-S3	$325.00
KM54479087418	KM544 MESA	SATIN BLACK W/ GRAY TINT	17X9	8X170	5.71	18mm	125.10	31.06 lbs	3640	1.87	T164H171-8-H77-S3	$325.00

Part#	Model	Finish	Size	Bolt Pattern	Backspace	Offset	Bore	Weight	Load	Lip Size	Cap	MSRP USD
KM54489050918	KM544 MESA	CANDY RED W/ BLACK LIP	18X9	5X127	5.71	18mm	71.50	34.54 lbs	2500	1.75	T164H120-5-H30-S5	$367.00
KM54489064918	KM544 MESA	CANDY RED W/ BLACK LIP	18X9	6X114.3	5.71	18mm	66.06	34.41 lbs	2500	1.75	T164H120-6-H30-S5	$367.00
KM54489068918	KM544 MESA	CANDY RED W/ BLACK LIP	18X9	6X139.7	5.71	18mm	106.10	32.81 lbs	2500	1.75	T164H145-6-H30-S5	$367.00
KM54489088918	KM544 MESA	CANDY RED W/ BLACK LIP	18X9	8X180	5.71	18mm	124.20	35.38 lbs	3640	1.75	T164H171-8-H65-S5	$367.00
KM54489058625	KM544 MESA	MATTE BRONZE W/ BLACK LIP	18X9	5X150	5.98	25mm	110.10	34.32 lbs	2500	1.75	T164H145-5-H30-S1	$367.00
KM54489064618	KM544 MESA	MATTE BRONZE W/ BLACK LIP	18X9	6X114.3	5.71	18mm	66.06	34.41 lbs	2500	1.75	T164H120-6-H30-S1	$367.00
KM54489068618	KM544 MESA	MATTE BRONZE W/ BLACK LIP	18X9	6X139.7	5.71	18mm	106.10	32.81 lbs	2500	1.75	T164H145-6-H30-S1	$367.00
KM54489080618	KM544 MESA	MATTE BRONZE W/ BLACK LIP	18X9	8X165.1	5.71	18mm	125.10	34.77 lbs	3640	1.75	T164H171-8-H65-S1	$367.00
KM54489087618	KM544 MESA	MATTE BRONZE W/ BLACK LIP	18X9	8X170	5.71	18mm	125.10	34.77 lbs	3640	1.75	T164H171-8-H77-S1	$367.00
KM54489088618	KM544 MESA	MATTE BRONZE W/ BLACK LIP	18X9	8X180	5.71	18mm	124.20	35.38 lbs	3640	1.75	T164H171-8-H65-S1	$367.00
KM54489058725	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	18X9	5X150	5.98	25mm	110.10	34.32 lbs	2500	1.75	T164H145-5-H30-S1	$367.00
KM54489068718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	18X9	6X139.7	5.71	18mm	106.10	32.81 lbs	2500	1.75	T164H145-6-H30-S1	$367.00
KM54489080718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	18X9	8X165.1	5.71	18mm	125.10	34.77 lbs	3640	1.75	T164H171-8-H65-S1	$367.00
KM54489087718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	18X9	8X170	5.71	18mm	125.10	34.77 lbs	3640	1.75	T164H171-8-H77-S1	$367.00
KM54489088718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	18X9	8X180	5.71	18mm	124.20	35.38 lbs	3640	1.75	T164H171-8-H65-S1	$367.00
KM54489058425	KM544 MESA	SATIN BLACK W/ GRAY TINT	18X9	5X150	5.98	25mm	110.10	34.32 lbs	2500	1.75	T164H145-5-H30-S3	$361.00
KM54489064418	KM544 MESA	SATIN BLACK W/ GRAY TINT	18X9	6X114.3	5.71	18mm	66.06	34.41 lbs	2500	1.75	T164H120-6-H30-S3	$361.00
KM54489068418	KM544 MESA	SATIN BLACK W/ GRAY TINT	18X9	6X139.7	5.71	18mm	106.10	32.81 lbs	2500	1.75	T164H145-6-H30-S3	$361.00
KM54489080418	KM544 MESA	SATIN BLACK W/ GRAY TINT	18X9	8X165.1	5.71	18mm	125.10	34.77 lbs	3640	1.75	T164H171-8-H65-S3	$361.00
KM54489087418	KM544 MESA	SATIN BLACK W/ GRAY TINT	18X9	8X170	5.71	18mm	125.10	34.77 lbs	3640	1.75	T164H171-8-H77-S3	$361.00
KM54489088418	KM544 MESA	SATIN BLACK W/ GRAY TINT	18X9	8X180	5.71	18mm	124.20	35.38 lbs	3640	1.75	T164H171-8-H65-S3	$361.00

Part#	Model	Finish	Size	Bolt Pattern	Backspace	Offset	Bore	Weight	Load	Lip Size	Cap	MSRP USD
KM54429050900	KM544 MESA	CANDY RED W/ BLACK LIP	20X9	5X127	5.00	00mm	71.50	38.59 lbs	2500	2.01	T164H120-5-H30-S5	$428.00
KM54429058925	KM544 MESA	CANDY RED W/ BLACK LIP	20X9	5X150	5.98	25mm	110.10	39.51 lbs	2500	1.69	T164H145-5-H30-S5	$428.00
KM54429063900	KM544 MESA	CANDY RED W/ BLACK LIP	20X9	6X135	5.00	00mm	87.10	37.64 lbs	2500	2.01	T164H140-6-H30-S5	$428.00
KM54429063918	KM544 MESA	CANDY RED W/ BLACK LIP	20X9	6X135	5.71	18mm	87.10	38.68 lbs	2500	1.69	T164H140-6-H30-S5	$428.00
KM54429068900	KM544 MESA	CANDY RED W/ BLACK LIP	20X9	6X139.7	5.00	00mm	106.10	36.87 lbs	2500	2.01	T164H145-6-H30-S5	$428.00
KM54429068918	KM544 MESA	CANDY RED W/ BLACK LIP	20X9	6X139.7	5.71	18mm	106.10	37.91 lbs	2500	1.69	T164H145-6-H30-S5	$428.00
KM54429080900	KM544 MESA	CANDY RED W/ BLACK LIP	20X9	8X165.1	5.00	00mm	125.10	39.04 lbs	3640	2.01	T164H171-8-H65-S5	$428.00
KM54429087900	KM544 MESA	CANDY RED W/ BLACK LIP	20X9	8X170	5.00	00mm	125.10	39.04 lbs	3640	2.01	T164H171-8-H77-S5	$428.00
KM54429088900	KM544 MESA	CANDY RED W/ BLACK LIP	20X9	8X180	5.00	00mm	124.20	39.65 lbs	3640	2.01	T164H171-8-H65-S5	$428.00
KM54429050618	KM544 MESA	MATTE BRONZE W/ BLACK LIP	20X9	5X127	5.71	18mm	71.50	39.63 lbs	2500	1.69	T164H120-5-H30-S1	$397.00
KM54429050600	KM544 MESA	MATTE BRONZE W/ BLACK LIP	20X9	5X127	5.00	00mm	71.50	38.59 lbs	2500	2.01	T164H120-5-H30-S1	$397.00
KM54429063600	KM544 MESA	MATTE BRONZE W/ BLACK LIP	20X9	6X135	5.00	00mm	87.10	37.64 lbs	2500	2.01	T164H140-6-H30-S1	$397.00
KM54429068600	KM544 MESA	MATTE BRONZE W/ BLACK LIP	20X9	6X139.7	5.00	00mm	106.10	36.87 lbs	2500	2.01	T164H145-6-H30-S1	$397.00
KM54429080600	KM544 MESA	MATTE BRONZE W/ BLACK LIP	20X9	8X165.1	5.00	00mm	125.10	39.04 lbs	3640	2.01	T164H171-8-H65-S1	$428.00
KM54429088618	KM544 MESA	MATTE BRONZE W/ BLACK LIP	20X9	8X180	5.71	18mm	124.20	42.72 lbs	3640	1.69	T164H171-8-H65-S1	$428.00
KM54429058725	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	20X9	5X150	5.98	25mm	110.10	39.51 lbs	2500	1.69	T164H145-5-H30-S1	$397.00
KM54429063718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	20X9	6X135	5.71	18mm	87.10	38.68 lbs	2500	1.69	T164H140-6-H30-S1	$397.00
KM54429063700	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	20X9	6X135	5.00	00mm	87.10	37.64 lbs	2500	2.01	T164H140-6-H30-S1	$397.00
KM54429068700	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	20X9	6X139.7	5.00	00mm	106.10	36.87 lbs	2500	2.01	T164H145-6-H30-S1	$397.00
KM54429068718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	20X9	6X139.7	5.71	18mm	106.10	37.91 lbs	2500	1.69	T164H145-6-H30-S1	$397.00
KM54429080718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	20X9	8X165.1	5.71	18mm	125.10	42.11 lbs	3640	1.69	T164H171-8-H65-S1	$428.00
KM54429080700	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	20X9	8X165.1	5.00	00mm	125.10	39.04 lbs	3640	2.01	T164H171-8-H65-S1	$428.00
KM54429087718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	20X9	8X170	5.71	18mm	125.10	42.11 lbs	3640	1.69	T164H171-8-H77-S1	$428.00
KM54429087700	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	20X9	8X170	5.00	00mm	125.10	39.04 lbs	3640	2.01	T164H171-8-H77-S1	$428.00
KM54429088718	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	20X9	8X180	5.71	18mm	124.20	42.72 lbs	3640	1.69	T164H171-8-H65-S1	$428.00
KM54429088700	KM544 MESA	SATIN BLACK W/ GLOSS BLACK LIP	20X9	8X180	5.00	00mm	124.20	39.65 lbs	3640	2.01	T164H171-8-H65-S1	$428.00
KM54429050400	KM544 MESA	SATIN BLACK W/ GRAY TINT	20X9	5X127	5.00	00mm	71.50	38.59 lbs	2500	2.01	T164H120-5-H30-S3	$392.00
KM54429050418	KM544 MESA	SATIN BLACK W/ GRAY TINT	20X9	5X127	5.71	18mm	71.50	39.63 lbs	2500	1.69	T164H120-5-H30-S3	$392.00
KM54429058425	KM544 MESA	SATIN BLACK W/ GRAY TINT	20X9	5X150	5.98	25mm	110.10	39.51 lbs	2500	1.69	T164H145-5-H30-S3	$392.00
KM54429063418	KM544 MESA	SATIN BLACK W/ GRAY TINT	20X9	6X135	5.71	18mm	87.10	38.68 lbs	2500	1.69	T164H140-6-H30-S3	$392.00
KM54429068418	KM544 MESA	SATIN BLACK W/ GRAY TINT	20X9	6X139.7	5.71	18mm	106.10	37.91 lbs	2500	1.69	T164H145-6-H30-S3	$392.00
KM54429068400	KM544 MESA	SATIN BLACK W/ GRAY TINT	20X9	6X139.7	5.00	00mm	106.10	36.87 lbs	2500	2.01	T164H145-6-H30-S3	$392.00
KM54429080400	KM544 MESA	SATIN BLACK W/ GRAY TINT	20X9	8X165.1	5.00	00mm	125.10	39.04 lbs	3640	2.01	T164H171-8-H65-S3	$421.00
KM54429080418	KM544 MESA	SATIN BLACK W/ GRAY TINT	20X9	8X165.1	5.71	18mm	125.10	42.11 lbs	3640	1.69	T164H171-8-H65-S3	$421.00
KM54429087418	KM544 MESA	SATIN BLACK W/ GRAY TINT	20X9	8X170	5.71	18mm	125.10	42.11 lbs	3640	1.69	T164H171-8-H77-S3	$421.00
KM54429087400	KM544 MESA	SATIN BLACK W/ GRAY TINT	20X9	8X170	5.00	00mm	125.10	39.04 lbs	3640	2.01	T164H171-8-H77-S3	$421.00
KM54429088418	KM544 MESA	SATIN BLACK W/ GRAY TINT	20X9	8X180	5.71	18mm	124.20	42.72 lbs	3640	1.69	T164H171-8-H65-S3	$421.00
KM54429088400	KM544 MESA	SATIN BLACK W/ GRAY TINT	20X9	8X180	5.00	00mm	124.20	39.65 lbs	3640	2.01	T164H171-8-H65-S3	$421.00
